Delta no longer considers this drive to be a core product. There is limited stock or long lead times. Call 800-985-6929 to check stock.

View and Download Delta VFD-L user manual online. VARIABLE SPEED AC MOTOR DRIVE 115V/230V 25W – 100W HIGH PERFORMANCE / EASY CONTROL AC DRIVE. VFD-L Controller pdf manual download. VFD-M Series DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Preface Thank you for choosing DELTA’s high-performance VFD-M Series. VFD-M Series are. Check to make sure that the package includes an AC drive, the User Manual, and rubber bushings. Inspect the unit to insure it was not damaged during shipment. Delta VFD-M-Catalog. Delta VFD-M-User-Manual. Delta VFD-M-A-PD 006 Spec Sheet. See the Delta VFD022M43B page on AutomatedPT.com. Purchase your Delta VFD022M43B TODAY! You Can Purchase your Delta AC Drive Panel’s with bypass and line reactor HERE! Please call, or email your Specs.!

Newer model recommended replacement drive:
Three Phase Input: VFD5A5MS43ANSAA

Delta Vfd B Operating Manual

Three Phase Input: VFD015EL43A

Always confirm drive specifications and call 800-985-6929 if you have any questions. Note VFD5A5MS43ANSAA and VFD022EL43A do not have the same dimensions, please verify replacement drive dimensions will fit your enclosure or mount.

Sensorless Vector Micro AC Drive. The compact design is ideal for small and medium horsepower applications. The M drive is designed to provide an ultra-low-noise operation, and includes several innovative technologies that reduce interference.

Delta Products
AC Drives, VFD-M Series

ITEM # VFD022M43B
MFG # VFD022M43B
Series VFD-M

Drive, AC, 3Hp, 460V Three Phase Input

Specifications
Item Number: VFD022M43B
Manufacturer: Delta Products
Item Category: Drives
Subcategory: AC
Series: VFD-M
Nominal Input VAC: 480 Volts AC
Input Range VAC: 380 to 480 Volts AC
HP (CT): 3 Horsepower
Amps (CT): 5 Amps
Input Phase: 3
Operator Controls: Keypad Included
Max. Frequency: 400 Hertz
Braking Type: DC Injection;Dynamic Braking
Motor Control-Max Level: Open Loop Vector (Sensorless Vector)
Closed Loop: No
AC Line Regenerative?: No
Dynamic Braking Trans?: Included
Enclosure Rating: IP20

Click on the links below to see Drawings and Specs:

Purchase your Delta VFD022M43B TODAY!

You Can Purchase your Delta AC Drive Panel’s with bypass and line reactor HERE

! Please call, or email your Specs. !

Delta Vfd M Manual Download

Delta Bypass Panels play an important role in a system to reduce energy usage,optimize AC motor speed control, extend motor life, and reduce overall cost. The bypass capabilities allow the motor to be operated from either the Delta VFD or at full speed, directly across the line. The Delta Bypass Panel sets a benchmark for cost, performance, quality, and custom engineered bypass panels. Delta offers both the standard bypass panel, or our custom engineered panel to fulfill all your specification requirements.

AC Motor Drive: VFD-M

Delta Vfd E

Features

Sensorless Vector Micro AC Drive. The compact design is ideal for small and medium horsepower applications. The M drive is designed to provide an ultra-low-noise operation, and includes several innovative technologies that reduce interference.

Specifications:

• Output frequency 0.1 ~ 400 Hz
• Adjustable V/f curve and vector control
• Carrier frequency up to 15 kHz
• Auto torque boost & slip compensation
• Built-in PID feedback control
• Built-in MODBUS communication, baud rate up to 38400 bps
• 0 speed holding function
• Built-in sleep / revival function
• Support communication module (DN-02, LN-01, PD-01)

Applications

Packing machine; dumpling machine; treadmill; temperature/humidity control fan for agriculture and aquaculture; mixer for food processing; grinding machine; drilling machine; small size hydraulic lathe; elevator; coating equipment; small size milling machine; robot arm of injection machine (clamp); wood machine (two-side woodworking planer); edge bending machine, elasticizer, etc.

For more info about this products, you may go to DELTA download center to get catalogs, manuals.. and much more.
